Osight XR Multi – Reticle System Rangefinder

Description

The Osight XR is a fully enclosed red dot sight designed for maximum durability, accuracy, and reliability during dynamic shooting. The fully enclosed emitter design provides excellent protection against dust, debris, and the elements, ensuring stable performance even in harsh conditions. The model uses the standard Ruggedized Miniature Reflex mounting footprint, allowing for broad compatibility with both full-size and compact pistols. The Osight XR features an innovative Multi-Reticle system with five different reticle configurations: 2 MOA dot, a 2 MOA dot with a 32 MOA circle, a 6 MOA dot, a 6 MOA dot with a 32 MOA circle, and a 32 MOA circle. This allows shooters to adapt their aiming according to distance, rate of fire, and the specific scenario. The sight also includes an innovative, collapsible, mechanical backup rear sight (Collapsible Backup Rear Sight-CBRS). If necessary, it can be quickly activated with the push of a button and provides a backup aiming system if the optic is turned off. The Osight XR is equipped with a patented magnetic charging cover that allows for easy and convenient charging of the sight. The cover displays the battery level in real time for both the sight itself and the charging module, ensuring constant monitoring of power. The aspherical lens guarantees a crystal-clear, distortion-free image, minimal parallax, and rapid target acquisition, making the Osight XR an excellent choice for sport, tactical, and dynamic shooting.

Osight XR Multi-Reticle System Specifications

• Multi-Reticle System-Easily switch between a 2 MOA dot, a 6 MOA dot, a 32 MOA circle, or a combination of dot and circle. The perfect solution for shooting in any scenario.
• Charging Cover Material: AL6061+PC
• Optics Material: 7075-T6 Aluminum
• Optics: Magnetic charging; Charging cover: USB-C charging
• Power source: Built-in 89mAh lithium-polymer rechargeable battery; Charging cover: Built-in 800mAh lithium-polymer rechargeable battery
• Adjustment: 1 MOA per click
• Brightness settings: 8 DL and 3 NV
• Light wavelength 660 nm
• Magnification 1x
• Maximum operating time 54,000 H (Mode 4, 2 MOA dot-only); 324,000 hours with charging cap (Mode 4, 2 MOA dot only)
• Memory function: Yes
• Motion sensor function: Yes
• Multi-layer coatings: Yes
• Parallax-free: Yes
• Reticle color: Red
• Reticle type: 2/6 MOA dot and 32 MOA circle
• Unlimited eye relief Yes
• Reticle movement range ± 45 MOA
• Window Size 0.91 x 0.71 inches (23 x 18 mm)
• Mounting Torque Specifications: M3 screw 15 in-lbs per screw; 4-40: 15 in-lbs per screw; 6-32: 17 in-lbs per screw; 6-40: 17 in-lbs per screw;
• Water resistance: IPX7; Charging port cover: IPX4
• Usage: Professional Use, Self-Defense, Home Security, Training, Competition
• Operating Temperature: 0-45°C (32-113°F)
• Dimensions (Length x Width x Height) Optics: 48.7 x 30 x 29.5 mm (1.91 x 1.18 x 1.16 inches) Loading cover: 51 x 36 x 42 mm (2.01 x 1.42 x 1.65 inches)
• Storage Temperature: -20-60°C (-4-140°F)
• Weight (g / oz) Optics: 48 g (1.69 oz); Charging cover: 55 g (1.94 oz)

PACKAGE CONTENTS

• Optical housing x 1
• Charging cover x 1
• USB-C charging cable x 1
• Adjustment tool x 1
• READ ME card x 1
• Silicone lanyard x 1
• Osight XR screw set x 1
• Pouch x 1
• Cleaning cloth x 1
• Safety warnings x 1
• User manual x 1
• Osight sticker x 1
